Keep It Clean
With SLIDE Products
At times like these we’re reminded of the importance of keeping our work environment and our tools clean. DME offers a wide range of cleaning products to support you every step of the way.
Mold Cleaners from Slide Products
Powerful, effective metal mold cleaners are available in formulations that meet your particular needs. Whether you need mold cleaners that degrease the mold, fast-evaporating cleaners, cleaners that work on warm molds, NSF registered, mold cleaners ideal for medical rooms or cleaners that remove the toughest resin deposits, you’ll find a solution using the Slide range of products…
Cleaning molds is a key part of running a successful injection molding operation. There are two situations when mold cleaning is required: (1) offline when the mold is on the bench and is cold (room temperature) and (2) online when the mold is warm and still in the press.
Because of temperature differences, the cleaning solvents may have different degrees of effectiveness. Solvents that work well on the bench and evaporate at a convenient rate are usually flashed off very rapidly on a hot mold and aren’t in contact long enough to do much cleaning.
Solvents that work well at higher temperatures are much less aggressive and effective at room temperature. They take longer to evaporate or may even have to be wiped off. Using the wrong cleaner may result in poor cleaning or excessive time to accomplish the job.
The requirements of offline cleaners are primarily to dissolve resins, degrease and remove oil, mold release and sometimes rust. These cleaners generally are required to have a very fast evaporation rate. The best cleaners for this are hydrocarbons and naphthas. They readily dissolve greases and oils by merely flushing the mold with a heavy spray from top to bottom.
Mold releases and resin build-up may require scrubbing the mold with a cloth saturated with the cleaner. Pre-saturated mold cleaning wipes are a great mold cleaning option, especially for medical molding and clean rooms. The advantages of using such a cleaning wipe include the following:
Guaranteed sterile, lint-free and mold cleaning cloth.
Ideal for precision cleaning of your mold
Pre-saturated with the ideal amount of mold cleaning solvent included
Easy-to-use and non-hazardous disposal
A final option for offline cleaning is the use of a metal mold polish and cleaning compound. These products are typically used in paste form and require manual application as well as removal. The typical mold polishing paste contains a combination of cleaning solvents and mild abrasives that are designed to aid with the removal of all contaminants from the mold or die surface.
An added benefit of using such a polishing paste is the resulting sheen or luster that is generally left on the mold surface. Such a finish serves as a natural lubricant and release, thus minimizing the need for a mold release to be used later once the mold is put back into production.
Online cleaners are generally used to remove mold release build up, plate out of resins and light rusting of the mold. Often molds get plate out, which is due to the adhesion of resins [acetals such as Delrin or Celcon have been common offenders in the past] or fire-retardant materials. Such build-ups must be chemically removed from the mold surface in order to minimize potential part deformation. A resin-removing product can chemically work to break down the material and to aid with the removal of the unwanted resin from the mold surface.
As a general rule, cleaning solvents used on a warm or hot mold should be much slower evaporating. This allows for the chemicals to remain on the mold surface for longer periods of time, thus maximizing the cleaning potential.
IPA IsoPropyl Alcohol Mold
Cleaner No. 47212
SLIDE® IPA IsoPropyl Alcohol Mold Cleaner provides a convenient method for removal of silicone, grease, oil and wax build-up on metal surfaces. Fast-evaporating solvent leaves no residue so there is no need for wiping. IPA Mold Cleaner has kosher-approved ingredients. California VOC compliant (74.9% VOC) and non-corrosive.
- No chlorinated solvents
- NSF category P1 (download NSF approval letter)
- Evaporates fast and leaves no residue
- Leaves no residue
- Kosher-approved ingredients
- Safe for use as a mold cleaner in food packaging applications
- California VOC compliant aerosol (74.9% VOC)
Mold Cleaner 4 No. 46910
- No chlorinated solvents
- NSF category P1
- Evaporates fast; leaves no residue
- Convenient method for removal of mold release, grease, oil and wax build-up on mold surfaces
- Slide’s most popular mold cleaner formulation
More SLIDE Cleaning Products
Click on a SLIDE Cleaning Product below for more information or to purchase that product.
Prevent rust with a protective film with the different Slide rust preventative products include aerosol sprays and liquids. Slide products stops rust and provides protection overnight, during short shutdowns and while in long-term storage. The Slide anti-rust oil-based aerosols and liquid compounds are great at stopping rust and are available in NSF registered formulations. Other rust preventatives include indicator dyes to make it easier to see where you have protection against rust, and where your steel mold us unprotected. Dry formulations will not bleed out and mark parts….
When your production run is done, as the mold is cooling, apply rust prevention spray to the mold cavity, the plates and mold base to help prevent condensation from causing rust and oxidation. This is a “dirty” step since the hot mold will likely cause the oils in a rust preventive to liquefy and run. It still protects the mold until it is cool enough to pull and take it to the tool room to break it down.
Now that you are in the tool room, break down the entire mold system to look for gas buildup, color stains, water stains, resinous deposits and any other contamination that might have built up on the mold unit during the production run. Use a solvent-based mold cleaner and/or mold polish to remove these contaminants and degrease the metal mold and give you a clean mold that is immediately ready to make parts when it comes out of storage.
Now protect the mold with a long-term rust preventive that is rated for the length of time you need protection while the mold is in storage. The American Society for Testing and Materials (ASTM) testing method for rust prevention designates a long-term rust preventive as being effective for up to 5 years of indoor storage. If you are storing a mold longer than 6 months, we recommend that the entire mold block (cavity as well as mold base) be protected with an oil-based rust preventive.
It is also best practice to crack open and inspect any mold stored for longer than 12 months, looking for any signs of corrosion. You should reapply a rust prevention product following these inspections to ensure all critical surfaces are protected.
Has your mold been running PVC or any other gas-emitting resin? Be sure to use a rust prevention product with protection against not only corrosion due to moisture, but also oxidation caused by the presence of the acidic vapors released by these
Mold Shield Rust Preventive No. 42910P
- No chlorinated solvents
- Unique “dry” formula
- 2-year protection*
- Will not bleed out and mark parts
- Neutralizes fingerprint acid
- Non-silicone, non-wax formulation
- Self-cleaning in start-up
- Seals out condensation
- Bulk versions of this product should be thoroughly stirred prior to use
Mold Release Agents
Mold Release Agents and Sprays
Mold release agents maximize productivity, help shorten mold cycle times, and help lengthen mold life. Aerosol spray mold release agents, applied properly to the mold surface, easily releases a variety of plastic resins. Mold release agents are available as aerosol sprays and bulk liquids, and are available in a variety of formulations, including NSF approved, to meet your specific molding application. Mold releases include formulations for engineered resins, thermosets, epoxies, and deep draw molding…
The Slide products have light duty, heavy duty, NSF approved releases, release for food applications, paintable, non-silicone, specialty releases and mold releases and investment casting.
Silicone mold release agents have been a staple in the molding industry for over 60 years. Sticky parts were the status quo during the infancy of the molding industry, and even as technology has evolved and mold design and mold making materials have improved, mold release agents still play a significant role in improving cycle times and helping eject sticky parts.
As molds get deeper into their cycle life, they may develop minor issues that don’t impact part finish or quality, yet create issues with parts ejecting. And this slows cycle times. A mold release spray may help extend the life of the mold before it requires significant maintenance or repairs.
Econo-Spray® 1 Mold Release Agent No. 40510P
- No chlorinated solvents
- Non-paintable silicone
- Approved for indirect food contact (†)
- Recognized by UL
- Safe to use on most resins
- Maximum operating temp: 600°F/315°C
More SLIDE and DME Products Available Online
Check out DME’s full portfolio of Cleaning Products, Mold Release Products, Lubricants and Rust Preventatives online 24/7. Click on a product below to view them on our eSTORE!
Quality You Can Trust
Not every product needs to conform to such exacting standards, but for those that do, DME supplies a range of lubricants, cleaners and protectors which conform to NSF guidelines. The NSF mark is your assurance that the product has been tested by one of the most respected independent certification organizations which is valued by consumers, manufacturers, retailers and regulatory agencies alike.
The NSF mark provides:
- Knowledge that an impartial review against established criteria has been conducted
- Evidence that product labelling has been objectively reviewed by a trusted third party
- A way to differentiate your product from your competitors’
- Evidence of your organization’s commitment to quality, compliance and safety
- Backing by a team of professionals dedicated to public health and safety
