DDS CATIA

DME offers cutting-edge design tools for streamlining the design processes. DME’s native Catia files database, which is designed for Catia Software users, supports the mold designer and overall molding process. Standard mold elements contain the parametric structure of components and are continuously updated by DME and our support partners.

Advantages of the native data (compared with STEP files or other exchange formats) is the ease with which components can be modified with consistency and speed. Manufacturer data (such as order reference and name of the product) are  defined in the file attributes. This optimizes handling of data in parts lists. Data is compiled in Catia V.5 / R2014 and can be downloaded via DME’s CAD portal.
